The Elumen8 Evora CMY350 Profile is a bright, feature-packed 350W LED moving head profile from Elumen8, distributed in the UK by Prolight Concepts. Full CMY colour mixing, twin rotating prisms, animation wheel, a 4-blade rotating framing system with shape rotation and a wide 3° to 53° motorised zoom, plus built-in W-DMX Sweden wireless. Dry hire from moving lights at STLS.
Specs At A Glance
| Fixture Type | LED moving head profile |
|---|---|
| Light Source | 1x 350W white LED, 6,900K |
| Lumens (Source / Output) | 20,500 lm / 13,000 lm |
| Beam Angle | 3° to 53° motorised zoom |
| Illuminance | 21,200 lux @ 10m (3°), 310 lux @ 10m (53°) |
| CRI | 71 standard / 84 with High CRI filter |
| Colour | CMY 0-100% + colour wheel (7 colours + High CRI filter + open) + variable CTO flag |
| Gobos | 7 rotating indexable + open, plus animation wheel (10 extra gobos included) |
| Framing | 4 rotating framing shutters ±45° with full shape rotation |
| Prism | 6-facet circular + 6-facet linear (both rotating, indexable) |
| Other Effects | Variable frost, motorised iris, variable strobe |
| Dimming | 0-100%, 5 modes (Standard, Stage, TV, Architectural, Theatre) |
| Refresh Rate | 14 presets, 900Hz – 25kHz (flicker-free for broadcast) |
| Movement | Pan 540° or 630° (selectable), Tilt 270°, 16-bit |
| DMX Modes | 34, 41 or 55 channels |
| Control | DMX, RDM, Art-Net, sACN, Kling-Net, W-DMX Sweden (built-in transceiver) |
| Data I/O | 5-pin XLR in/out, etherCON in/out, integral Art-Net node relay |
| Power | PowerTwist TR1 in/out |
What’s Included In Dry Hire
Each Elumen8 Evora CMY350 Profile hire comes with quick-release omega clamps (included by manufacturer), a safety bond, PowerTwist TR1 power lead and an extra 10 rotating gobos. PAT certificate on request. Add DMX cable or top loaders to your order as needed.
Key Features
- 350W white LED at 6,900K, 20,500 lumens source and 13,000 lumens output
- Wide 3° to 53° motorised zoom for tight beams and broad projection
- Full CMY colour mixing plus 7-colour wheel with High CRI filter option (CRI 71 to 84)
- Variable CTO flag for continuous colour temperature control
- 4-blade rotating framing shutters (±45°) with full frame shape rotation
- 7 rotating, indexable, replaceable gobos plus a dedicated animation wheel
- Both circular and linear rotating prisms (6-facet each, indexable)
- Variable frost filter and motorised iris
- Flicker-free LED with 14 refresh rate presets from 900Hz to 25kHz
- 5 dimming modes tailored for stage, TV, theatre and architectural work
- Built-in W-DMX Sweden wireless transceiver, no external receiver needed
- Integral Art-Net node relays DMX to fixtures downstream on the same universe
- Selectable 540° or 630° pan and 270° tilt with 16-bit positioning
- PowerTwist TR1 power and etherCON data throughput
- 2-year manufacturer warranty on the fixture
- Ships with 10 additional rotating gobos as standard
Common Uses
Rental, touring, theatre productions, TV broadcast, awards, corporate stages and concert use. The Evora CMY350 is aimed at the rental market and delivers a high-feature-count moving profile in a manageable footprint – perfect for rigs where you want CMY mixing, framing shutters and animation wheel effects without stepping up to bigger 600W-class fixtures.
Elumen8 Evora Series Range
The Elumen8 Evora family covers a wide range: Evora CMY350 Profile (this one), Evora CMY600 Profile (bigger 600W-class sibling), Evora CMY470 Hybrid (beam/spot/wash hybrid), Evora CMY300 Zoom Spot, Evora 850 Zoom Spot, plus the Evora 740ZP and 1940ZP Zoom Wash. Match the fixture to your rig scale.
Similar Or Alternative Fixtures
Need different options? See our moving light range for Martin Mac Viper Profile (1000W discharge equivalent), Robe LED Beam 350, Robe Pointe and other LED profiles. Need a desk to programme it? See lighting control hire for Chamsys MagicQ, ETC Eos and Avolites options with CRMX/W-DMX bridge support.
Frequently Asked Questions
What brand makes the Evora CMY350?
Elumen8, a professional lighting brand distributed in the UK by Prolight Concepts. Part of the Elumen8 Evora range.
Is the Evora CMY350 LED or discharge?
LED. Single 350W white LED engine at 6,900K, 20,500 lumens at source. Instant on, no lamp swaps and lower power draw than discharge equivalents.
What’s the zoom range?
3° to 53° motorised zoom. Wide range from razor-tight aerial beams up to broad projection washes.
Does it have framing shutters?
Yes. Four rotating framing shutters (±45°) with full shape rotation for clean edge control on gobo and spot projection.
How many DMX channels does the Evora CMY350 use?
34, 41 or 55 channels selectable, depending on level of control you need. The 55-channel mode gives full fine-mode access to every effect.
Does it have wireless DMX?
Yes. Built-in W-DMX Sweden transceiver. No external receiver or dongle needed. It can also relay wireless DMX out via the XLR output to feed downstream fixtures.
What’s the CRI?
71 standard, rising to 84 with the High CRI filter engaged. Suitable for stage, broadcast and higher colour-accuracy applications.
What effects does it have?
CMY mixing, colour wheel (7 colours + High CRI filter), variable CTO flag, 7 rotating gobos, animation wheel, both circular and linear rotating prisms, variable frost, motorised iris and variable strobe.
Does it support Art-Net and sACN?
Yes. Full networking with DMX, RDM, Art-Net, sACN and Kling-Net. Integral Art-Net node relays signal down to standard DMX fixtures downstream.
What power connector does it use?
PowerTwist TR1 in and out for daisy-chaining. Data via 5-pin XLR or etherCON.
Are extra gobos included?
Yes. The fixture ships with 10 additional rotating gobos on top of the seven standard fixture gobos.
How does it compare to the Elumen8 Evora CMY600 Profile?
The CMY350 is the 350W-class fixture. The CMY600 is the bigger 600W-class sibling with higher output for larger stages. Pick the 350 for tighter budgets and portable rigs; step up to the 600 for bigger venues.
